| Print cartridge volume delivered |
500 ml
|
| Ink types |
Pigment-based (C, M, Y, K)
|
| Number of print cartridges |
4 (C, M, Y, K)
|
| Print heads |
8 (C, M, Y, K)
|
| Print quality color (best) |
1200 x 1200 dpi
|
| First page out |
22 sec (from USB)
|
| Media sizes standard (metric rolls) |
279 to 1016 mm
|
| Media weight, supported |
70 to 200 g/m²
|
| Roll external diameter |
Up to 177 mm
|
| Roll maximum input |
2 rolls default with auto-switching, expandable to 4 rolls
|
| Roll maximum output |
Up to 200 m
|
| Core size |
7.6 cm
|
| Recommended media |
HP Universal Bond Paper, 3-in Core (FSC® certified) (recyclable); HP Production Matte Poster Paper, 3-in Core (FSC® certified) (recyclable); HP Production Satin Poster Paper, 3-in Core (FSC® certified) (recyclable); HP Universal Heavyweight Coated Paper, 3-in Core (FSC® certified) (recyclable); HP Matte Polypropylene, 3-in Core
|
| Media thickness |
Up to 15.7 mil
|
| Media thickness (metric) |
Up to 0.4 mm
|
| Paper handling output, optional |
High-capacity stacker (up to 500-page capacity), online folder (only compatible in conjunction with the optional accessory upgrade kit)
|
| Paper handling output, standard |
Top stacker (up to 100-page capacity)
|
| Supported Primary Applications |
Line drawings; Maps; Orthophotos; Posters
|
| Media types |
Bond and recycled papers, poster papers, polypropylene, Tyvek papers, matte film
|
| Media weight, recommended |
70 to 200 g/m²
|
| Internal Storage |
500 GB HDD (AES-256 encrypted)
|
| Line accuracy |
±0.1%
|
| Print languages |
HP-GL/2, TIFF, JPEG
|
| Warm-up time |
No warm up
|
| Description |
Large-format color MFP
|
| Print technology |
HP PageWide Technology
|
| Theoretical minimum line width |
0.02 mm (HP-GL/2 addressable)
|
| Optional printer languages |
Adobe PostScript 3, Adobe PDF 1.7 (with PostScript/PDF upgrade)
|
| Printing path |
HP SmartStream software (optional), HP Click printing software, HP PageWide XL print drivers (PDF, HP-GL/2, and PCL3), Apple AirPrint
|
| Maximum copy length |
9.5 m
|
| Scan resolution, optical |
1200 dpi
|
| Linear scan speed |
Color: up to 15.24 cm/sec; Grayscale: up to 25.4 cm/sec
|
| Scan file format |
JPEG, TIFF, multi-TIFF, PDF, PDFA, multi-PDF, multi-PDFA (with PostScript/PDF upgrade)
|
| Scan input modes |
Printer storage, USB drive, network folder (SMB), My home folder, scan to email, scan to HP SmartStream software
|
| Maximum media thickness |
0.26 mm
|
| Scan size, maximum |
Up to 914 mm
|
| Scanner type |
36-in (91-cm) CIS scanner
|
| Maximum scan length |
50 m (PDF), 12 m (TIFF), 8 m (JPEG)
|
| Scanner advanced features |
Live preview, scan quicksets, smart background removal, black enhancement, automatic de-skew, reduce scan speed, post-edit settings (contrast, brightness, rotation, cropping and skew)
|
| Connectivity, standard |
Gigabit Ethernet (1000Base-T), USB 2.0 host
|
| Interface |
15.6-inch (396-mm) TFT (LED blacklight) 16:9-format HD capacitive touchscreen
|
| Infrastructure management |
HP Partner Link, HP Embedded Web Server, HP Web Jetadmin, PrintOS
|
| Minimum dimensions (W x D x H) |
1955 x 785 x 1414 mm
|
| Package dimensions (W x D x H) |
2257 x 1040 x 1578 mm
|
| Weight |
452 kg
|
| Package weight |
621 kg
|
| Processor |
Intel Celeron
|
| Memory |
8 GB DDR4
|
| Acoustic power emissions (active, printing) |
≤7.8 B(A) (operating), ≤5.5 B(A) (idle), ≤3.5 B(A) (sleep)
|
| Acoustic pressure emissions |
≤60 dB(A) (operating), ≤36 dB(A) (idle), ≤20 dB(A) (sleep)
|
| Operating humidity range |
20 to 80% RH, depending on media type
|
| Operating temperature range |
5 to 40°C
|
| Operating temperature range |
41 to 104°F
|
| Power consumption |
0.27 kW (typical); 0.7 kW (max printing); 95 W (ready); <16 W (sleep)
|
| Power |
Input voltage (auto ranging) 100-127/200-240 V (±10%), 50/60 Hz (±3 Hz), 7/3.5 A
|
| Electromagnetic compatibility |
Compliant with Class A requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia and New Zealand (RCM), Japan (VCCI), Korea (KC)
|
| Energy star certified |
Yes
|
| Environmental certification |
ENERGY STAR, EPEAT Registered, UL 2801 ECOLOGO, CE marking (including RoHS, WEEE, REACH). In compliance with WW RoHS materials restriction requirements in China, Korea, India, Vietnam, Turkey, Serbia, and Ukraine
|
| Safety |
IEC 60950-1+A1+A2 and IEC 62368-1 2nd ed. compliant; USA and Canada (CSA listed); EU (LVD and EN 60950-1 and 62368-1 compliant); Russia, Belarus, and Kazakhstan (EAC); China (CCC)
|
| Manufacturer Warranty |
90 days
|
